Membranes for flow batteries and electrolysers
Membranes for flow batteries and electrolysers - Image 2
Membranes for flow batteries and electrolysers - Image 3

Membranes for flow batteries and electrolysers

Price range: 35.00 € through 425.00 €

Precision-engineered ion exchange membranes for advanced electrochemical applications, including flow batteries and electrolysers.

Read more about the product

▲ ▼

About the product

Our selection of high-performance ion exchange membranes from Fumatech are essential components for a wide range of electrochemical applications, from redox flow batteries to water electrolysis. These membranes serve as a reliable separator and ion conductor, crucial for achieving high efficiency and performance in your research and development.

We offer a variety of both anion and cation exchange membranes, each tailored for specific applications such as Vanadium Redox Flow Batteries (VRFB), organic flow batteries, and water electrolysis. The membranes are available in various thicknesses and with different reinforcement materials to ensure optimal performance and mechanical stability.
To suit your specific research needs, we provide membranes in several formats:

  • Standard Sheets: 12.5 x 12.5 cm and 20 x 30 cm sheets for custom cutting.
  • Pre-Cut for Our Cells:
    • Cut w. alignment holes: For all our single cell test hardware.
    • Cut for X-Stack: Perfectly sized for our X-Stack electrolyser.
    • Cut for S-Stack: Designed for our S-Stack flow battery.
    • Cut with manifold holes: For our 3 and 4-compartment X-Cell.

For other dimensions or specific cut-outs, please make an inquiry. We are happy to provide custom solutions for your project.
We offer a range of membranes with different properties to suit various applications. The table below summarizes the key technical specifications for our most popular membranes.

Membrane
Type
Application
Thickness (µm)
Reinforcement
Key Features
FAP-450
Anion Exchange
Flow Batteries
50
None
High efficiency for VRFB
FAPQ-330
Anion Exchange
Flow Batteries
30
None
High power density for VRFB
FS-930
Cation Exchange
Flow Batteries
30
Microporous
High current density for VRFB
FAAM-20
Anion Exchange
Alkaline Electrolysis
20
None
For alkaline water electrolysis
FAAM-PK-75
Anion Exchange
Alkaline Electrolysis
75
PEEK
Mechanically robust for alkaline systems
F-10150-PTFE
Cation Exchange
PEM Electrolysis
150
PTFE
High pressure operation in PEMWE



For more detailed information and technical datasheets, please refer to the manufacturer’s website:


Datasheets for specific membranes are available for download on the Fumatech website.

Support & Inquiry

Do you have specific questions or would you like help in selection and configuration of our product:

Membranes for flow batteries and electrolysers

You are very welcome to contact us in the form here. We are ready to support you in selecting the best solutions for your R&D.

Always include as much information as you can about your project, what type of chemistry you are planning to use, what is the purpose of the equipment  you are interested in. That will make it much easier for us to guide you towards the best solution for your project.
