fumasep® FAS-PET-75/130 Anion Exchange Membrane

Price range: 35.00 € through 185.00 €

The fumasep® FAS-PET-75/130 is a PET-reinforced anion exchange membrane with low resistance, high selectivity (>92–93%) and high mechanical stability, available in 75 µm and 130 µm for electrodialysis in neutral and acidic media (pH 0–9).

Read more about the product

Nominal dry thickness

Size

Package

Clear

▲ ▼

About the product

The fumasep® FAS-PET is a PET-reinforced anion exchange membrane from Fumatech for electrodialysis (ED). It is designed for demineralisation, desalination and salt concentration, especially in neutral to acidic media, and is a cost-effective, mechanically robust option for ED research.

It comes in two thicknesses. The 75 µm version has the lowest area resistance (<2.5 Ω·cm²) for minimal cell voltage. The 130 µm version (<3.5 Ω·cm²) offers slightly higher selectivity (>93% vs >92%) and extra robustness. Area resistance is measured in Cl⁻ form in 0.5 M NaCl at 25 °C. The woven PET reinforcement keeps both versions dimensionally stable in the x/y-direction.

The membrane is supplied dry, in bromide (Br⁻) form, and can be cut in the dry state. Before use, condition it in 0.5–1 M NaCl solution at ambient temperature until equilibrated, keeping it fully immersed. Avoid surfactants, organic substances and oxidants.

Both versions are stable across pH 0–9 at 25 °C, with an operating temperature range of 15–40 °C. For strongly alkaline conditions, choose the PK-reinforced FAS-PK.

Main application area: Anion transport in ED; demineralisation, desalination and salt concentration, particularly in neutral/acidic media.

Property	Unit	FAS-PET-75	FAS-PET-130
Membrane type		Anion exchange membrane	Anion exchange membrane
Appearance		Brown	Brown
Reinforcement		PET	PET
Counter ion		Bromide (Br⁻)	Bromide (Br⁻)
Delivery form		Dry	Dry
Thickness (dry)	µm	60 – 90	110 – 150
Area resistance in Cl⁻ form in 0.5 M NaCl at T = 25 °C	Ω cm²	< 2.5	< 3.5
Permselectivity 0.1 / 0.5 M KCl at T = 25 °C	%	> 92	> 93
pH stability range at T = 25 °C	pH	0 – 9	0 – 9
Operational temperature range	°C	15 – 40	15 – 40

Technical Datasheet fumasep® FAS-PET-75/130
