fumasep® FKB-PK-75/130 Cation Exchange Membrane

Price range: 35.00 € through 185.00 €

The fumasep® FKB-PK-75/130 is a PK-reinforced cation exchange membrane with low resistance, high selectivity (>92–93%) and very high mechanical stability, available in 75 µm and 130 µm and stable across pH 0–14.

Read more about the product

Nominal dry thickness

Size

Package

Clear

▲ ▼

About the product

The fumasep® FKB-PK is a PK (polyketone)-reinforced cation exchange membrane from Fumatech for electrodialysis (ED) and electrodialysis with bipolar membranes (EDBM). It is a versatile cation exchange membrane for desalination, salt concentration and acid/base production. Fumatech also uses it as the standard CEM when characterising its FBM bipolar membrane.

It comes in two thicknesses. The 75 µm version offers very low area resistance (<2.5 Ωcm²) for energy-efficient operation. The 130 µm version (<5.0 Ωcm²) offers slightly higher selectivity (>93% vs >92%) and extra mechanical robustness. Area resistance is measured in Cl⁻ form in 0.5 M NaCl at 25 °C. The PK reinforcement gives high stability in acidic and caustic environments.

The membrane is supplied dry, in K⁺ form, and can be cut in the dry state. Before use, condition it in 0.5–1 M NaCl solution at ambient temperature until equilibrated, keeping it fully immersed. Avoid surfactants, organic substances and oxidants.

Both versions are stable across pH 0–14 at 25 °C, with an operating temperature range of 15–40 °C.

Main application area: Cation transport in ED and EDBM; desalination, salt concentration and acid/base production.

Property	Unit	FKB-PK-75	FKB-PK-130
Membrane type		Cation exchange membrane	Cation exchange membrane
Appearance		Light brown	Light brown
Reinforcement		PK (polyketone)	PK (polyketone)
Counter ion		K⁺ form	K⁺ form
Delivery form		Dry	Dry
Thickness (dry)	µm	60 – 90	120 – 150
Area resistance in Cl⁻ form in 0.5 M NaCl at T = 25 °C	Ω cm²	< 2.5	< 5.0
Permselectivity 0.1 / 0.5 M KCl at T = 25 °C	%	> 92	> 93
pH stability range at T = 25 °C	pH	0 – 14	0 – 14
Operational temperature range	°C	15 – 40	15 – 40

Technical Datasheet fumasep® FKB-PK-75/130
