Graphite Bipolar Plates for S-Cell and S-Stack (1)

BP-Gr-S-001

295.00 €

Thickness: 2mm
Hard graphite/polymer composite
Amount: 1 piece per package

About the product

Designed for S-cell and S-stack applications, these high-quality bipolar plates deliver exceptional performance with excellent electrical conductivity, mechanical strength, impermeability, and outstanding corrosion resistance. Crafted as 2 mm thick plates using a durable graphite/polymer composite, their superior properties are achieved through an innovative manufacturing process and the use of premium raw materials.

Density: 1.92 g/cm³
Resistivity: 9 μΩ·m
Compressive Strength: 100 MPa
Flexural Strength: 60 MPa
Shore Hardness: 65 HSD
Air Permeability: Non-Permeable
Working Temperature: 150–250 °C
