S-Stack Frame

FCP-SS-01-002

$3 534.10

This is the frame, for the S-Stack with all components, except for the individual cells.

Read more about the product

Standard Endplate, Threaded

Standard Endplate, No Thread

Standard Isolator (NBR) × 2

Graphite flow body for S-Cell (1/4") × 2

Graphite flow-body (replacement part) for the S-Cell Flow-battery cell and the S-Stack.
- 1 piece per package (two needed per cell)
- Can be operated in full pH range – from strongly acidic to strongly alkaline
- Comes with PFA Swagelok connectors (for 1/8" tubing)

2 mm Banana Plugs (1) × 2

2 mm Banana plug with wire
Amount: 1 Piece per package

Gold plated copper current collectors × 2

2 current collectors included

Graphite Bipolar Plates for S-Cell and S-Stack (1)

Thickness: 2mm
Hard graphite/polymer composite
Amount: 1 piece per package

Allignment bars for cell assembly (1) × 4

Length: 15 cm or 9.5 cm
Diameter: 6 mm
Material: PEEK
Amount: 1 piece per package

Length

15 cm

O-Ring × 5

EPDM O-ring til 5/16 fitting - 6 mm (ID) x 2.6 mm thickness
EPDM O-ring til 5/16 fitting - 7.5 mm (ID) x 2 mm thickness
EPDM O-ring til 5/16 fitting - 5 mm (ID) x 3 mm thickness
EPDM O-ring til 5/16 fitting - 6 mm (ID) x 2.5 mm thickness
VITON O-ring til 5/16 fitting - 6 mm (ID) x 2.6 mm thickness
VITON O-ring til 5/16 fitting - 7.5 mm (ID) x 2 mm thickness
VITON O-ring til 5/16 fitting - 5 mm (ID) x 3 mm thickness
VITON O-ring til 5/16 fitting - 6 mm (ID) x 2.5 mm thickness

EPDM O-ring - 9.6 mm (ID) x 2.5 mm thickness
VITON O-ring - 9.6 mm (ID) x 2.5 mm thickness

EPDM O-ring - 10 mm (ID) x 2.5 mm thickness
VITON O-ring - 10 mm (ID) x 2.5 mm thickness

EPDM O-ring til 1/2 fitting - 12.7 mm (ID) x 2.62 thickness
VITON O-ring til 1/2 fitting - 12.7 mm (ID) x 2.62 thickness

EPDM O-ring til 5/8 fitting - 15.54 mm (ID) x 2.62 thickness
VITON O-ring til 5/8 fitting - 15.54 mm (ID) x 2.62 thickness

EPDM O-ring 8.04 mm (ID) x 1.00 thickness
VITON O-ring 8.04 mm (ID) x 1.00 thickness

EPDM O-ring 29.08 mm (ID) x 1.02 thickness
VITON O-ring 30 mm (ID) x 1.00 thickness

EPDM O-ring 24 mm (ID) x 1.00 thickness
VITON O-ring 24 mm (ID) x 1.00 thickness

EPDM 9x4 - ORS117889
EPDM 10x4 -ORS11502
EPDM 11x3 - ORS13942
EPDM 12x3 - ORS11259
VITON/FKM 9x4 - ORS160030
VITON/FKM 10x4 - ORS160064
VITON/FKM 11x3 - ORS165490
VITON/FKM 12x3 - ORS160132

Inner Diameter

10mm

Gasket material

Viton

Thickness

2.5mm
